[FPCAD V2.0] Grade Pipe Planning
Command Line: F2TG
Application for designing and developing grade end pipe flattening (inclined) directly in AutoCAD, with the following entries:
> Primitive diameter
> greater height
> Lower Height
Click here and learn about the applications available so far:
-----------------------------------------------------------------------------------
F1: Commands for drawing machine elements
-----------------------------------------------------------------------------------
F1POL: Draw A-channel pulleys,B,C or D
F1COR: Draw transmission chain
-----------------------------------------------------------------------------------
F2: Commands for Flattening Geometries
-----------------------------------------------------------------------------------
F2GR: Draw the plan of ANGULAR CUT TUBE
F2GO: Draw and plan BEND CURVE
F2TR: Design the TRANSITION plan
F2CO: Draw the CONE TRUNK plan
F2HE: Design the planning of HELICOIDAL THREAD
------------------------------------------------------------------------------------
F3: Command for drawing structural beams and profiles
------------------------------------------------------------------------------------
F3E: Draw views F / L / S of the following profiles:
-----------------Profile W Gerdau
-----------------Profile M
-----------------HP Profile
-----------------American Standard I Profile
-----------------American Standard U Profile
-----------------Parallel U abas Profile
-----------------Inclined U abas profile
-----------------Inch standard angle bracket
-----------------Half WT profiles / MT / ST
-----------------Custom L profile
-----------------Custom U profile
-----------------Custom Z profile
-----------------Tubo SCH.5 / SCH.10 / SCH.40 / SCH.80s
-----------------XS tube / XXS
-----------------Industrial tube OD Pol.
-----------------Industrial Tube OD Square Pol.
-----------------Industrial Tube OD Rectangular Pol.
-----------------W Metric Profile
-----------------Metric square industrial tube
-----------------Metric rectangular industrial tube
-----------------metric U profile
-----------------Profile L metric unequal tabs
-----------------------------------------------------------------------------------
F4: Commands for balloons and automatic calculation of gross weight in bills of materials
-----------------------------------------------------------------------------------
Note: Necessary to follow standard list template description attached to FPCAD
------------------------------------------------------------------------------------
F4A: Automatically updates the unit and total gross weight of just one list item
F4E: Edits the bill of materials and automatically updates the unit and total gross weight
F4S: Sums the total gross weight of the list and plots on the sheet
F4T: Automatically updates the unit and total gross weight of all list items
F4X: Automatically deletes and resets all selected weight values
F4B: Create call and identification balloons, with manual input
F4N: Create numeric callout and identification balloons, with automatic sequential > 1-2-3-4.....
------------------------------------------------------------------------------------
